Current and voltage notes: the key ideas
What do current and voltage measure?
Electric circuits can seem mysterious because you cannot see what is moving. Two measurements describe what is going on: how much charge flows, and how hard the supply pushes it.
Electric current is the rate at which electric charge flows past a point in a circuit. It is measured in amperes (A) with an ammeter.
Voltage, also called potential difference, is the energy transferred to each unit of charge by a cell, or from the charge by a component. It is measured in volts (V) with a voltmeter.
| Quantity | Symbol | Unit | Meter | How it is connected |
|---|---|---|---|---|
| Current | I | ampere (A) | Ammeter | In series (in the loop) |
| Voltage | V | volt (V) | Voltmeter | In parallel (across the part) |
Small currents are often given in milliamperes. One ampere is 1000 milliamperes, so you divide by 1000 to change mA into A.
I (A) = I (mA) ÷ 1000
I is the current. A is the ampere and mA is the milliampere.
Ayesha in Dhaka reads 250 mA on a meter in her phone charger circuit. Convert the reading to amperes.
I = 250 mA ÷ 1000 = 0.250 A.
How do you connect an ammeter and a voltmeter?
An ammeter must have the same current flowing through it as the part you are measuring, so you cut the circuit and put it in the loop, in series. A voltmeter measures the difference between two points, so you join it across the component, in parallel.
Never connect an ammeter across a component or across a cell. An ammeter has almost no resistance, so it makes a short circuit, and a large current can damage the meter or the cell. A voltmeter in series stops nearly all of the current.
What are the rules for current in series and parallel circuits?
In a series circuit the current is the same everywhere in the loop. In a parallel circuit the currents in the branches add up to the current in the main wire.
I = I₁ + I₂ + …
For a parallel circuit: I is the current in the main wire (A). I₁, I₂ are the currents in the branches (A).
Kofi in Accra measures 0.80 A in the main wire of a parallel circuit and 0.50 A in one branch. Calculate the current in the second branch.
I₂ = 0.80 A − 0.50 A = 0.30 A.
What are the rules for voltage in series and parallel circuits?
In a series circuit the voltages across the components add up to the supply voltage. In a parallel circuit the voltage across each branch equals the supply voltage.
V = V₁ + V₂ + …
For a series circuit: V is the supply voltage (V). V₁, V₂ are the voltages across the components (V).
Mei in Singapore connects two bulbs in series to a 6.0 V supply. A voltmeter across the first bulb reads 2.5 V. Calculate the voltage across the second bulb.
V₂ = 6.0 V − 2.5 V = 3.5 V.
| Quantity | Series circuit | Parallel circuit |
|---|---|---|
| Current | Same everywhere in the loop | Branch currents add up to the main current |
| Voltage | Shared between the components | Same across every branch |
Remember “A in line, V across”: the ammeter goes in the line of the circuit and the voltmeter goes across the part you want to measure.
- Current is measured in amperes (A) with an ammeter in series.
- Voltage is measured in volts (V) with a voltmeter in parallel.
- Series: same current everywhere; voltages add up to the supply.
- Parallel: branch currents add up (I = I₁ + I₂); same voltage across each branch.
- 1 A = 1000 mA, so divide by 1000 to change mA into A.
Reading ammeters and voltmeters in circuits: frequently asked questions
How do you connect an ammeter in a circuit?
Connect the ammeter in series, by breaking the circuit and putting it in the loop so that all the current to be measured passes through it. Never put an ammeter straight across a component or a cell.
How do you connect a voltmeter in a circuit?
Connect the voltmeter in parallel, with one lead on each side of the component. It measures the voltage across that component without being part of the main path.
What is the rule for current in a series circuit?
The current is the same at every point in a series circuit. The charge has only one path, and it is not used up by the components.
What is the rule for current in a parallel circuit?
The currents in the branches add up to the current in the main wire. For example, 0.50 A and 0.30 A in two branches give 0.80 A in the main wire.
How does voltage behave in series and parallel circuits?
In a series circuit the voltages across the components add up to the supply voltage. In a parallel circuit each branch has the same voltage as the supply.
